BLU-6

ウォールマウント コントローラー

BLU-6
拡大画像

The BLU-6 wall panel is a simple controller which allows the designer to provide level control and source selection or preset recall in a simple wall-mounted panel.

These controllers connect to the control ports on the rear of any BLU-16, BLU-32 or BLU-80 device.

The BLU-6 offers an eight-way switch and a pair of spin or up/down buttons, enabling the same level parameter to be mapped onto other controllers preventing a jump in audio level when the control is adjusted

The switches have blank areas for marking the switch functions, either directly onto the white area, or on self-adhesive labels.

ダウンロード

ドキュメント
  言語 サイズ アップロード日
file type icon BLU-6 CAD 図面(前面)
en 更新: 2026年4月
en  29.1KB 2026年4月
file type icon BLU-6 カットシート-英語
en 更新: 2026年4月
en  196KB 2026年4月
file type icon BLU-6 インストールガイド-英語
en 更新: 2026年4月
en  680KB 2026年4月
file type icon BLU-6 クイックスタートガイド-英語
en 更新: 2026年4月
en  904KB 2026年4月
Brochures
  サイズ アップロード日
file type icon Soundweb London Family Brochure
更新: 2020年10月
1.3MB 2020年10月
Software
  バージョン サイズ アップロード日
Windows download icon HiQnet London Architect
バージョン 6.02.R3, リリース日: 2023年11月
6.02.R3   117MB 2023年11月
Data Sheets
  サイズ アップロード日
file type icon Soundweb London A&E Specs
更新: 2020年10月
73KB 2020年10月

上記のリンクをクリックしてブラウザで文字化けが発生する場合は、ファイルを右クリックしてコンピューターに保存してください。

仕様

Chassis Single-Gang EU
Control In Analog (two wire)
Controls 8-position source/preset select, up/down buttons
Config Software
