MC-1
Tidak diproduksi

Fiber Optic Media Converter

MC-1
Gambar Lebih Besar

The MC-1 is a Gigabit Media Converter which provides transport up to 10 km (6.2 miles) using 1310nm single mode fiber cable. In use, an MC-1 will be utilized on each end of a two conductor single mode fiber optic cable deployed between two equipment rack locations.

The MC-1 is supplied with a wall mount bracket and external power supply.

The MC-1 utilizes automatic link restoration which re-establishes network links between two MC-1 devices should a connected Soundweb London device be disconnected and reconnected to the network. This eliminates the need to reset the MC-1 after patching or power loss of an attached Soundweb London device.

Status LEDs on the MC-1 provide indication of Power (PWR), Fiber Link RX (RXF), Fiber Link TX (LKF), Copper RX (RXC), and Copper TX (LKC).

Fitur

KEY FEATURES

  • Gigabit Media Conversion
  • Automatic Link Restoration
  • External 12V DC Power Supply
  • Status LEDs
  • 10 km (6.2 miles) Transmission Distance Using 131Onm Single Mode Fiber Cable
  • SC Style Fiber Connector
  • RJ45 Copper Connector

Unduhan

Dokumen
  Bahasa Ukuran Diunggah
file type icon MC-1 Gambar CAD Depan
en diperbarui: Apr 2026
en  759 KB Apr 2026
file type icon MC-1 Lembar Data-Inggris
en diperbarui: Apr 2026
en  632 KB Apr 2026
file type icon MC-1 Panduan Instalasi-Inggris
en diperbarui: Apr 2026
en  1,82 MB Apr 2026
Brochures
  Ukuran Diunggah
file type icon Soundweb London Family Brochure
diperbarui: Okt 2020
1,3 MB Okt 2020

Jika ada tautan di atas yang menampilkan karakter aneh di browser Anda, klik kanan file tersebut untuk menyimpannya ke komputer Anda.

Spesifikasi

Connectors SC fiber optic, Gigabit RJ45
Power Supply Included external 12V DC, 1.5A with wall-mount bracket
Display Status LEDs
