Wall Panel

Larger Images

Where installations require a simple hardware controller, the 9012 provides an instant solution for volume and source select functions (for example). The 9012 is equipped with a rotary fader and a five-position switch, connecting to the control port inputs on the rear of a Soundweb 9088 or 9000 device. These controls may be mapped in Soundweb Designer to utilise other functions.

The 9012 is provided along with a set of multi-purpose lables, in four languages - English, French, German, and Spanish.


  Version Language Size Uploaded
file type icon 9012US CAD drawing front
en updated: Sep 2023
  en  3.76 MB Sep 2023
file type icon 9012US Cut Sheet-English
en updated: Sep 2023
  en  690 KB Sep 2023
file type icon 9012US Install Guide-English
en updated: Sep 2023
  en  904 KB Sep 2023

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.


Chassis Single-Gang US
Control In Analog (two wire)
Controls 5-position source/preset select, level
Config Software
