BSS OMNI-VD-660

Larger Images

The BSS OMNI-VD-660 is an AV-over-IP decoder for distributing 4K60 4:4:4 video, audio, control, and USB 2.0 signals over Gigabit Ethernet, in environments ranging from classrooms and meeting rooms to courtrooms, hospitality venues, and large enterprise or government facilities.

At the core of the OMNI-VD-660 is the Motion Wavelet Compression (MWC) codec, engineered for pristine visual quality and ultra-low encode to decode latency with fast-motion video, high-detail graphics, and dynamic visual content. Additionally, the OMNI-VE-660 features standards-based 1080p H.264 or H.265 decoding, for receiving bandwidth-efficient streams from third-party devices or platforms, or compatible OMNI networked AV encoders over WANs or shared networks.

The OMNI-VD-660 features USB 2.0 routing and extension through Virtual Network USB 2.0 Hub technology. A host PC, connected to an OMNI 600 encoder, can communicate with USB devices located at up to four OMNI-VD-660 decoders or 200 Series device transceivers, supporting USB 2.0 data rates up to 480 Mbps. This capability allows host PCs to interface with cameras, conferencing bars, touch displays, HID peripherals, and other devices at remote locations across the network.

Along with high-performance networked AV distribution, the OMNI-VD-660 is Dante AV-A enabled for interoperability with third-party Dante AV-A encoders. Integrators can configure and manage OMNI 600 systems using Dante Controller, Dante Domain Manager, and Dante Director. In addition, this decoder supports two-channel Dante audio input and output.

The OMNI-VD-660 is designed for modern professional AV installations, with essential integration features including PoE+ remote powering, a low-power standby mode, video stream preview, custom image and slideshow presentations, open APIs for third-party control, 4K video scaling, and video wall processing.

HIGH-PERFORMANCE NETWORKED AV DISTRIBUTION

Powered by Motion Wavelet Compression (MWC), OMNI 600 delivers pristine-quality 4K60 4:4:4 video with ultra-low latency. This ensures high-quality presentation of fast-motion video and high-detail content for demanding AV applications.
USB ROUTING OVER IP

Virtual Network USB 2.0 Hub technology enables a USB host, connected to a host transceiver or encoder, to communicate with USB devices at up to four remote endpoints, with support for high-bandwidth conferencing devices as well as HID peripherals.
DANTE AUDIO AND DANTE AV-A INTEROPERABILITY

Built-in Dante AV-A compatibility enables interoperability with third-party Dante AV-A devices and system configuration and management through Dante Controller, Dante Domain Manager, and Dante Director. Additionally, each encoder and decoder supports two-channel Dante audio input and output.
ENTERPRISE-GRADE NETWORK SECURITY

BSS OMNI AV over IP incorporates comprehensive network security features and standards to meet the security and operational requirements of enterprise networks.
CENTRALIZED SYSTEM MANAGEMENT

AVX Suite is the essential resource for BSS OMNI AVoIP system management which includes device discovery and configuration, virtual matrix switching, firmware updates, system monitoring, and more.

HIGH-PERFORMANCE NETWORKED AV DISTRIBUTION

Powered by Motion Wavelet Compression (MWC), OMNI 600 delivers pristine-quality 4K60 4:4:4 video with ultra-low latency. This ensures high-quality presentation of fast-motion video and high-detail content for demanding AV applications.

USB ROUTING OVER IP

Virtual Network USB 2.0 Hub technology enables a USB host, connected to a host transceiver or encoder, to communicate with USB devices at up to four remote endpoints, with support for high-bandwidth conferencing devices as well as HID peripherals.

DANTE AUDIO AND DANTE AV-A INTEROPERABILITY

Built-in Dante AV-A compatibility enables interoperability with third-party Dante AV-A devices and system configuration and management through Dante Controller, Dante Domain Manager, and Dante Director. Additionally, each encoder and decoder supports two-channel Dante audio input and output.

ENTERPRISE-GRADE NETWORK SECURITY

BSS OMNI AV over IP incorporates comprehensive network security features and standards to meet the security and operational requirements of enterprise networks.

CENTRALIZED SYSTEM MANAGEMENT

AVX Suite is the essential resource for BSS OMNI AVoIP system management which includes device discovery and configuration, virtual matrix switching, firmware updates, system monitoring, and more.

Features

AV-over-IP decoder for 4K60 4:4:4 video, audio, control, and USB 2.0 over Gigabit Ethernet
High-performance MWC codec delivers pristine-quality video with ultra-low latency
Standards-based 1080p H.264 or H.265 decoding
Virtual Network USB 2.0 Hub for routing between a USB host and devices at up to four remote locations
Dante AV-A enables interoperability with third-party networked AV encoders, plus system management from Dante Controller, Dante Domain Manager, and Dante Director
Two-channel Dante audio input and output (2x2)
Video preview from the built-in web interface or a touch panel
Supports custom image and slideshow presentations
Enhance video presentations with 4K video scaling, seamless switching, and video wall processing
PoE+ powered with low-power (standby) mode to conserve energy
Enterprise-grade network security and standards including IEEE 802.1x, HTTPS, TLS, AES-256 encryption, LDAP, VLAN tagging, and QoS
AVX Suite for OMNI 600 system configuration and management
HARMAN HControl and BSS Direct Control provide open APIs for third-party control integration
UL2043 certification for plenum space installation

Videos

Downloads

Spec Sheets

	Language	Size	Uploaded
OMNI-VD-660 Spec Sheet updated: Jul 2026		856 KB	Jul 2026

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Specifications

Video Outputs	HDMI
Video Resolution Support	480p, 720p, 1080p, 1200p, 1440p, and 4K *See Appendix in manual
Audio Inputs	PCM or Dante
Audio Outputs	Embedded Audio on HDMI Analog Stereo (Balanced) Dante
Ports	+12V 2A DC power input, (P0) Gigabit Ethernet port with PoE+ support, (P1) Gigabit Ethernet port, (IR Out) 2-pin 3.5mm screw terminal, (RS232) 3-pin 3.5mm screw terminal, (Audio Out) 5-pin 3.5mm screw terminal, HDMI video output, USB Type-A USB 2.0 device port, (2) USB Type-A HID device port
Environmental	Temperature – 32° to 104°F (0° to 40°C) Humidity – 10% to 90% RH (non-condensing) Heat Dissipation – 85 BTU/hr
Dimensions (H x W x D)	1 1/6" x 7 7/8" x 5" (26.6mm x 200mm x 127mm)
Product Weight	2.16 lbs. (Approx. 0.97kg)
SKU Numbers	BSS-VD660

Accessories

ACC-MR-NAV10 | 10 Unit Rack Mount Kit with Active Fan Cooling

Larger Images

The BSS ACC-MR-NAV10 is a rack mount accessory that provides ten vertical slots for installing OMNI Networked AV products in an equipment rack. The ACC-MR-NAV10 occupies up to 8 RU of space, including 6 RU for the enclosure and 2 RU to allow ventilation. It provides active cooling with upper and lower trays of cooling fans to ensure ample air circulation. Any unoccupied slots can be covered with the ACC-MR-NAVB1 accessory panel.

The ACC-MR-NAV10 is compatible with the OMNI 600 and 300 Series, as well as the OMNI 200 Series with two units installed side by side.

Documentation

ACC-MR-NAV10 Spec Sheet (EN) [781 KB]

ACC-MT-NAV1 | 1 Unit Multi-Mount Kit

Larger Images

The BSS ACC-MT-NAV1 is an accessory for installing an OMNI AVoIP product below a meeting table, or onto a wall or other surface. It provides a secure, screw-mounted connection that allows simple product removal if necessary. A detachable strain relief plate is included for securing cables into place.

In addition to under-table or surface mounting, the ACC-MT-NAV1 can be used for pole mounting, or installation onto a US or EU/UK electrical junction box. It also includes VESA 100 mm spacing for mounting behind a display. This accessory is compatible with the OMNI 600 and 300 Series, as well as the OMNI 200 Series.
